9522-13 Swivel metric, DKOS (STEEL)

Type

DKOS (interlock)

Material

Fe/Zn

	Article	DN (inch)	DN (mm)	Ø (DIN)	Thread	Ø	S	PU	Stock	Listprice
	9522-13-20-12	3/4	20	20S	METRIC	M30x2	36	1	In stock	€ 33,55
DN (inch) 3/4 DN (mm) 20 Ø (DIN) 20S Thread METRIC Ø M30x2 S 36 more info »
	9522-13-25-12	3/4	20	25S	METRIC	M36x2	46	1	In stock	€ 28,56
DN (inch) 3/4 DN (mm) 20 Ø (DIN) 25S Thread METRIC Ø M36x2 S 46 more info »
	9522-13-25-16	1	25	25S	METRIC	M36x2	46	1	In stock	€ 42,28
DN (inch) 1 DN (mm) 25 Ø (DIN) 25S Thread METRIC Ø M36x2 S 46 more info »
	9522-13-30-16	1	25	30S	METRIC	M42x2	50	1	In stock	€ 26,41
DN (inch) 1 DN (mm) 25 Ø (DIN) 30S Thread METRIC Ø M42x2 S 50 more info »
	9522-13-30-20	1.1/4	32	30S	METRIC	M42x2	50	1	In stock	€ 53,36
DN (inch) 1.1/4 DN (mm) 32 Ø (DIN) 30S Thread METRIC Ø M42x2 S 50 more info »
	9522-13-38-20	1.1/4	32	38S	METRIC	M52x2	60	1	In stock	€ 42,51
DN (inch) 1.1/4 DN (mm) 32 Ø (DIN) 38S Thread METRIC Ø M52x2 S 60 more info »
	9522-13-38-24	1.1/2	40	38S	METRIC	M52x2	60	1	In stock	€ 73,13
DN (inch) 1.1/2 DN (mm) 40 Ø (DIN) 38S Thread METRIC Ø M52x2 S 60 more info »
